Laser cutting provides you a large range of advantages: High accuracy and low heat influence. The fibre laser, additionally, offers high efficiency and low maintenance. As the laser beam is guided via a fibre cable, no adjustment is necessary between laser source and carriage. Also, no purging gas is needed. With a wall plug efficiency up to 30%, the fibre laser is much more efficient than the CO2 Laser. The cutting quality in mild steel is comparable up to 20 mm thickness. Stainless steel and aluminium are also possible. Thus, the fibre laser is a flexible and easy tool that also offers the key advantages high accuracy and low heat input
Your Advantages:
- Low maintenance
- High efficiency
- Robust design
- Easy handling
- Mild Steel up to 20 mm with good cutting quality
- Stainless steel up to 10 mm, Aluminium up to 8 mm
Fibre laser bevel cutting
Bevel cutting in principle is a process that shows high know-how and requires sophisticated control. This is made possible for bevel cutting with the infinitely rotating bevel head from Messer Cutting Systems. However, the machine control takes over the complex tasks, and handling remains simple.
In mild steel, besides straight cuts, also V- and Y- cuts are possible. Here a deep know-how of the application is needed, especially when two cuts along one contour are made. Angles from -45° up to +50° and maximum thicknesses of 15 mm are possible.
Additionally, special know how and equipment is available to make bevel cuts in stainless steel
Your Advantages:
- Infinitely rotatable bevel unit
- Protection of bevel head by patented magnetic holder
- Reliable stand-off control with capacitive height sensing
- Continuous adjustment of the bevel angle during the cut
- Bevel cuts in mild steel and stainless steel with high precision (+/- 0.1 mm for straight cuts, +/- 0.5 mm for bevel cuts)
- Maximum thickness: 15 mm
- Continuous bevels from -45° up to +50°
